MCP Tool Design Agents Get Right: Schemas, Errors, and Structured Output

Two servers can expose the same database and behave like different products. With one, the agent picks the right tool, fills the arguments correctly, recovers from failures, and finishes the task. With the other, it loops, guesses, apologizes, and gives up. The difference is almost never the model; it is tool design. This part turns the naive tools from Part 2 into tools that agents reliably get right: descriptions written for a reader that decides in one pass, schemas that make invalid calls impossible, an error contract that teaches instead of punishes, and structured output that downstream code can consume without parsing prose.

1. Your API consumer reads, it does not browse

Every habit you have from designing REST APIs needs one adjustment here: the consumer of your tools reads the documentation in full, every request, and decides under time pressure. The model sees a flat list of names, descriptions, and schemas. It does not click through examples or remember yesterday's calls. So the design goal is choosability: from the description alone, can a reader tell exactly when this tool is the right one, and when it is not?

Three rules follow. Name tools verb_noun and keep one job per tool: search_notes, create_note, never notes_api with a mode argument. Make the first sentence of the description the decision rule, what it does and when to reach for it; put when not to use it explicitly if a sibling tool overlaps. And prefer a handful of task-shaped tools over a mirror of your internal endpoints; the model is completing a task, not exploring your architecture. If your service has twenty endpoints, your server probably wants five tools.

2. Schemas that make bad calls impossible

A description persuades; a schema enforces. FastMCP builds schemas from type hints, and the hints can carry much more than a bare type. Pydantic Field metadata adds per-argument descriptions and constraints, Literal turns a string into an enum the model cannot stray from, and defaults mark what is genuinely optional. Every constraint you encode is a class of failed calls that can no longer happen.

from typing import Annotated, Literal

from pydantic import Field

@mcp.tool()
def create_note(
    title: Annotated[str, Field(
        description="Unique title for the note",
        min_length=3, max_length=80,
    )],
    body: Annotated[str, Field(
        description="Note body, plain text or Markdown",
    )],
    visibility: Literal["private", "team"] = "team",
) -> str:
    """Create a new note. Use only for new titles; to change an
    existing note, use update_note instead."""
    notes = _load()
    if title in notes:
        return (f"A note titled {title!r} already exists. "
                f"Use update_note to change it, or pick a new title.")
    notes[title] = body
    _save(notes)
    return f"Created {visibility} note {title!r}."

The Literal is the quiet hero. Without it, the model will eventually send visibility values like public, shared, or Team, and your code grows defensive branches. With it, the schema advertises exactly two values and validation rejects everything else before your function runs. The same thinking applies to numeric ranges with ge and le, and to formats: if an argument is a date, say so in the field description and give the format you expect. The playground below shows the enforcement layer in miniature, a validator like the one the SDK runs in front of every call.

3. The error contract: teach, do not punish

MCP has two distinct failure layers, and using the right one is half of error design. A protocol error, the JSON-RPC error object from Part 1, means the machinery failed: unknown tool, invalid arguments, server crash. A tool error is different: the call worked, but the task could not be done, and the result carries isError true with content explaining why. The model only sees and reasons about the second kind, which means the text you put there is not logging, it is course correction.

Write tool errors the way you would write a code review comment for a capable colleague: state what failed, why, and what to do instead. The duplicate-title message in create_note above is the pattern: it names the conflict and offers both exits. In FastMCP, raising an exception inside a tool produces an isError result automatically, so the practical rule is: raise for genuine bugs and broken invariants, return guidance-shaped text for expected failures the model should route around.

4. Structured output: results code can trust

Strings are fine when the consumer is only the model, but agents increasingly pipe tool results into further computation, and parsing prose is how that breaks. Since the 2025-06-18 revision, tools can declare an output schema and return structured content alongside the readable text. In FastMCP, you get this by returning a Pydantic model: the SDK derives the output schema, serializes your instance into structuredContent, and keeps a text rendering for hosts that only show text.

from pydantic import BaseModel

class NoteStats(BaseModel):
    title: str
    word_count: int
    headings: list[str]
    last_modified: str

@mcp.tool()
def note_stats(title: str) -> NoteStats:
    """Compute statistics for one note: word count, headings, and
    last modified time. Read-only."""
    notes = _load()
    if title not in notes:
        raise ValueError(f"No note titled {title!r}")
    body = notes[title]
    return NoteStats(
        title=title,
        word_count=len(body.split()),
        headings=[l.lstrip("# ") for l in body.splitlines()
                  if l.startswith("#")],
        last_modified=_mtime_iso(),
    )

Now a client that needs the word count reads structuredContent.word_count, validated against the declared schema, instead of regexing a sentence. Use structured output whenever the result has fields a program might care about, and keep returning plain strings for results that are inherently narrative. The two coexist happily in one server, and nothing about the model's experience gets worse: it still receives readable text.

5. Annotations: telling hosts what is safe

Hosts gate tool calls behind user approval, but they cannot read your code to know which calls are harmless. Tool annotations are standardized hints that carry exactly that knowledge: readOnlyHint marks tools with no side effects, destructiveHint warns that effects may be irreversible, idempotentHint says repeating a call changes nothing further, and openWorldHint distinguishes tools that touch the wider world from ones that stay inside your domain.

from mcp.types import ToolAnnotations

@mcp.tool(annotations=ToolAnnotations(
    readOnlyHint=True,
    openWorldHint=False,
))
def search_notes(query: str, limit: int = 5) -> str:
    """Search saved notes by keyword across titles and bodies."""
    ...

@mcp.tool(annotations=ToolAnnotations(
    destructiveHint=True,
    idempotentHint=False,
))
def delete_note(title: str) -> str:
    """Permanently delete one note by exact title. Cannot be undone."""
    ...

A host can use these to auto-approve read-only calls in a trusted session while always confirming destructive ones, which directly improves the agent's flow through your server. Two honesty rules: annotations are hints, not security, so Part 6 still applies in full; and a wrong annotation is worse than none, because a destructive tool marked read-only will eventually be auto-approved into disaster. Annotate what the code actually does.

6. Results that respect the context window

One last craft point: tool results land in the model's context, and context is the scarcest resource in the system. A search that returns five hundred full notes does not make the agent better informed, it makes it worse at everything that follows. Build limits into the schema with sane defaults, truncate long fields with an explicit marker and a way to get the rest, and when a result set is naturally large, return a page plus a cursor argument for the next call rather than everything at once. The grain to aim for: each result should carry just enough for the model to decide its next step, with a cheap path to drill in.

The bottom line

Good MCP tools are choosable from one read, constrained so bad calls die at validation, honest about failure in text the model can act on, structured when programs consume the result, and annotated so hosts know what is safe. None of this needed new infrastructure, only the discipline to treat the model as the user it is. The server is now well designed but still local and wide open. Next we put it on the network with Streamable HTTP and mount it inside a FastAPI application, the bridge to running this in production.

Up next: Part 5, Streamable HTTP and mounting MCP in FastAPI.
